How to Customize

We specialize in crafting custom bags to perfectly fit your frame, your style and your adventure.
See options below, and then order here.

Fabric

Our fabrics are selected based on durability, weight and function to ensure our gear is game for the most demanding adventures. All our fabrics are waterproof, with a large selection of colors in our two standard options and a handful of specialty fabrics for those looking for something more specific.

*Click the swatches for enlargement and fabric identification.

ECOPak EPX-200

One of our go-to fabrics, EPX-200 is a great balance of durability and weight with a 200D face and 70D ripstop backing. Environmentally focused, it boasts 100% recycled polyester components, C0 DWR (no fluorocarbons), and can be recycled at end of life.

​

  • 6.4oz/sq yd, 216 gsm

  • 3-layer construction

  • 100% Polyester

  • Produced in China

  • Colors available: Bright Orange, Fuchsia, Deep Purple, Flamingo Pink, Bright Blue, Lilac, Ocean Blue, Wolf Grey, Coyote Brown, Brick Red, Tropic Teal

X-Pac VX21

Our other standard fabric with similar attributes to the EPX-200, VX21 utilizes 210D face paired with a 50D taffeta backing and DWR finish.


  • 6.2 oz/sq yd, 210 gsm

  • 4-layer construction

  • 60% Nylon, 40% Polyester

  • Produced in USA

  • Colors available: Black, Coyote Brown, Bahama Blue, True Red, Deep Blue, Federal Yellow

​ECOPak EPX70RS

​

Same environmental attributes as the EPX-200, but lighter weight.

  • 70D ripstop face, 70D back

  • 5.05 oz/sq yd, 171 gsm

  • Colors available: Cire Black, Matte Black​​​​​​​​​​​​

​ECOPak EPX600

​

This heavy hitter is all about durability and abrasion resistance.

  • 600D face, 70D ripstop back

  • 9.97 oz/sq yd, 338 gsm

  • Colors available: Black Knight, Multi Cam​​​​​

Challenge Sail Cloth UltraGrid

​

UltraGrid is 100% recycled nylon from pre-consumer industrial waste and uses C0 DWR.

  • 200D face, PU backing (2 layers)

  • 4.3 oz/sq yd, 146 gsm

  • Not recommended for frame bags

  • Colors available: Black Beauty, Avocado

Dyneema Composite Fabric

​

Established for its incredible strength to weight ratio, this laminate fabric is the ultimate choice for those looking for ultralight gear.

  • 2.92 oz/sq yd

  • Colors available: White, Black, Blue​​​​

Mounting

We offer three ways to secure your frame bag to your bike. Selection is based on your bike’s components and your personal preferences. Combinations are possible.

Reinforced Velcro Tabs

Our standard mounting option allows for straps to be placed where they need to be for even distribution of weight and accommodation of components. Velcro tabs allow the bag to be removed quickly from the bike, which can be preferable to some but a security risk to others.

Direct Mount

Direct mounts can be located where your bike has bottle bosses on the interior of the frame. It utilizes the existing screw paired with a nylon washer to compress the bag to the frame through a reinforced hole. Some prefer them as they provide a clean look, less rubbing on the frame and added security as they are harder to remove. Direct mounts have an additional cost.

Lacing

Lacing utilizes elastic cord and webbing loops along the lengths of the bag, providing an even anchor from bag to bike. This options is often chosen for its added security (harder to remove) and less rubbing on frame. Lacing has an additional cost.

Zippers

We offer two zipper options:

​

  • YKK#8 Aquaguard (coil)

  • Paskal #8 PU Coated Molded Vislon tooth



Both are water resistant. We find that many PNW customers (and others that play in wet and muddy conditions) prefer the coil zipper while the toothed zipper excels in drier climates.

Additional Features

True custom means refining and dialing it in, and we’re here for it. Below are additions you can add to your bag. Want something not listed? Let’s chat!

  • Hydration Port

  • Zipper Divider

  • Tapered Perimeter Width

  • ​Internal Pockets

  • Custom Printing

  • ​Logo patches or printing

Pic-Fit

​

Let’s get your custom FRAME bag rolling!
Follow these simple steps to send us the perfect reference photo.



1. Point-of-Reference

  • Take an 8.5" x 11" sheet of white paper and fold it in half.

  • Using a thick dark marker, draw a 6" line in the center, adding hash marks every inch.*

  • Tape the paper to the top tube of your bike.


*Be accurate with your line and hash marks, the fit of your bag is based on these measurements.

2. Grab Your Bike

  • With the paper attached, place your bike parallel to a flat surface (like a wall).

  • Align the crankarms so they’re parallel with the floor.

  • Choose a wall that contrasts with your bike frame for better visibility.

  • Natural daylight works best—avoid harsh shadows when possible.


3. Say Cheese!

Before you take your photo, keep these tips in mind:

  • If you want a direct-mount frame bag, make sure all bottle and mounting bosses are visible.

  • Mount any other bags you normally use (top tube bag, seat post bag, etc.) so we can check for strap clearance.



Positioning:

  • Stand at least 15 feet from your bike.

  • Keep the camera/phone lens level with the middle of your bike’s triangle.

  • Make sure both wheels are fully visible—back up if needed.

  • The further away you are (while keeping the paper’s line visible), the more accurate the image will be.



Snap that pic!


4. Check and Send

Choose the best photo and double-check:

  • Only one chainstay is visible.

  • Only one seatstay is visible.

  • Only one fork leg is visible.

  • Zoom in to confirm the reference line and hash marks are clearly visible.



Save your file using this format: NAME_INVOICE#



Email your Pic-Fit to: info@loamequip.com
